Electric Motor In-slot Stator Needle Winding Machine with Wire
Can be equipped with 3 needle (wire nozzle) for winding at the same
time, just one station with oter ring protection. It can achieve
auto wire hooking, cutting, arraying and winding on stators
(1) Technical Parameters
|Needle number||1~3 needles|
|Stator stack height||≤80mm with plastic frame|
|Wire diameter range||Φ0.08~Φ1.0 mm|
|Load winding speed||≤600 r/min|
|Winding precision||±0 turn|
(2) Brief Instruction of Machine
Machine "Electric Motor In-slot Stator Needle Winding Machine with
Wire Protection" is used for winding electric wires on stators
automatically and directly.
(3) Main Specifications
1. The machine is suitable for brushless DC in-slot converter
motors in the field of automobile, household appliance and air
etc., like servo motor, fan motor, washing machine motor,
compressor motor and stepper motor, etc.;
2. CNC controls servo motor to achieve high-speed running and
3. It can achieve auto winding, arraying, indexing, hooking and
cutting, fault diagnosis function and so on.
Combining years of experience, we can provide high-qualified
machines which are simple operated and easy for maintenance,
including single set machine or whole production line machines.
Before placing an order, we can have a technical discussion if
customers have any doubt. And if customers have any requirement in
design or allocation, we also will try our best to satisfy them.
Besides, our warranty time is one year and during this period,
we’ll offer some spare parts for free if they’re broken due to
quality issue or design issue. Before delivery, we’ll also offer
some wearing parts for free.
When customers have some problems with the machine, inform us and
our after-sales engineers will be in customer’s site in the
(5) Production Line Design
With good service, professional team and reliable quality, SMT
provide customer with different kinds of equipments for various
motors production. It can be one set machine or the whole
prodcuting line from winding process to final forming process. So
if customer wants the whole production line, we can provide
manufacturing technical consulting service and Turn-key projecting
service, including the motor cost evaluation, manufacturing
know-how, staff training, even complete turn-key project.
